兆赫级诊断边缘AI硬件模拟器发布

A packet-level digital hardware twin for commissioning megahertz diagnostic edge AI and plasma control system integration in tokamaks

精选理由

托卡马克控制系统的硬件模拟器,解决高采样率诊断路径的调试难题,提供可复现测试环境。

研究人员开发了包级数字硬件孪生系统,用于兆赫级诊断边缘AI架构。该系统模拟64通道、1兆赫束发射光谱(BES)诊断,嵌入96通道双载波采集系统。

正文

系统每秒生成50,000个数据包,用户负载达100MB/s,中位延迟为91.6微秒,99百分位延迟为108.

1微秒。

原文 · arXiv cs.AI

A packet-level digital hardware twin for commissioning megahertz diagnostic edge AI and plasma control system integration in tokamaks

High-bandwidth plasma diagnostics increasingly provide inputs to machine learning and signal-processing algorithms intended for real-time tokamak control, but the complete path from diagnostic sampling to control-system handoff is difficult to commission because of their sampling rates. We develop a packet-level digital hardware twin for the megahertz diagnostic edge-AI architecture. The simulator represents a 64-channel, 1 MHz beam emission spectroscopy (BES) diagnostic embedded in a 96-channel dual-carrier acquisition system, two 48-channel streams with SPAD0 sample counters, 10 GbE Hardware UDP transport, packet loss and network jitter, FPGA parsing and dual-carrier alignment, causal preprocessing and edge inference, a compact Ethernet result packet, receiver-side shared state, and a 1 kHz PCS-like control cycle. Binary UDP payloads and PCAP files are generated rather than emulating transport only at the array level. With a baseline of 20 samples per packet, each carrier generates 50,000 packets s$^{-1}$ and 100 MB s$^{-1}$ of user payload. A 110 ms reference run produces 11,000 HUDP packets; an intentionally dropped 20-sample packet is detected by the sample-counter continuity logic and invalidates the two overlapping 128-sample inference windows without silent interpolation. For valid windows, the configured engineering latency model gives a median last-input-to-shared-memory latency of 91.6 us and a 99th percentile of 108.1 us. A separate operating-system loopback test sends binary FPGA-result datagrams through a UDP receiver into POSIX shared memory and preserves packet sequence and CRC for 20/20 packets. Interactive GUI interfaces expose timing, packetization, network faults, inference thresholds, and control-state inspection. The framework provides a reproducible environment for testing diagnostic-to-accelerator interfaces and fail-safe behavior for deployment on fusion devices.
